RSSI analysis becomes much easier when you can see the signal changing instead of watching a stream of numbers in a terminal. A chart makes it possible to notice movement, sudden drops, periods of instability, and differences between devices almost immediately.

In this project, we use a BleuIO USB dongle with Python and Plotly Dash to build a live BLE signal strength analyzer. The application scans nearby BLE advertisers, lets us select a device, and follows its RSSI over time. It also provides a quick overview of every device currently being discovered.

This is intended as a starting point rather than a complete positioning or ranging system. If you already work with RSSI, the dashboard gives you a practical base for collecting observations, testing an environment, and extending the analysis for your own use case.

What the analyzer provides

The dashboard is organized around one selected BLE device. Its current RSSI, smoothed RSSI, recent trend, and signal stability appear directly above a live time-series chart. The raw readings remain visible, so the processed line never hides what the dongle actually received.

Below the main analysis, the Discovered Now section compares the latest RSSI values from nearby devices. An RSSI distribution chart shows how the selected device’s readings are spread across the recent observation window.

This combination is useful when you want to answer practical questions such as whether a signal is consistently weak, whether it is changing direction, or whether an apparently stable device is producing occasional large variations.

Hardware and software

You will need:

• A BleuIO USB dongle
• Python 3.10 or newer
• The project source code on GitHub

The application uses pySerial to communicate with BleuIO and Plotly Dash for the local dashboard. BleuIO handles the BLE radio operation, so the Python application only needs to work with its serial AT-command interface.

Download and install the project

Clone the repository and move into the project directory:

git  clone  https://github.com/smart-sensor-devices-ab/bleuio-rssi-analyzer.git

cd  bleuio-rssi-analyzer

On macOS or Linux, create a virtual environment and install the dependencies:

python3  -m  venv  .venv

source  .venv/bin/activate

python  -m  pip  install  -r  requirements.txt

On Windows PowerShell, use:

py -m venv .venv

.venv\Scripts\Activate.ps1

python -m pip install -r requirements.txt

Connect the BleuIO dongle before starting the application. BleuIO briefly exposes its bootloader after power-up, so allow approximately 15 seconds for the normal application serial port to appear.

Start the analyzer:

python  app.py

Then open http://127.0.0.1:8050 in a browser.

Start scanning

The serial-port menu only shows ports identified as BleuIO devices. On macOS, this normally looks like /dev/cu.usbmodem.... On Windows, the dongle may appear as a generic USB Serial Device (COMx), so the application also recognizes BleuIO by its USB vendor and product identifiers.

Select the dongle and click Start scan. The application places BleuIO in central role and repeatedly performs a short timed scan using AT+GAPSCAN=1. Repeating the timed scan gives the dashboard a continuing series of fresh RSSI observations instead of a single discovery result. The command behavior is documented in the BleuIO AT command reference.

As advertisements are received, nearby addresses appear in the BLE device menu. Select the device you want to examine, and the analysis area updates immediately.

Follow a selected signal

The Current RSSI card displays the most recent reading. This value is useful for immediate feedback, but normal radio variation can make it jump even when neither device has deliberately moved.

The Smoothed RSSI view makes the overall movement easier to follow. The project first applies a short median filter to reduce isolated spikes, followed by an exponentially weighted moving average that gives more importance to recent observations. The original samples remain visible as dots, while the smoothed result appears as the blue line.

This processing is deliberately lightweight. It is enough to make the live chart readable, but it is also easy to replace if your experiment needs a Kalman filter, a different smoothing window, or no filtering at all.

Read the trend and stability indicators

The Recent Trend card compares the latest smoothed value with the recent signal history. A change of at least 4 dB is described as Getting stronger or Getting weaker. Smaller changes are shown as Stable. The card also displays the measured change, making the label easy to interpret rather than presenting it as an unexplained classification.

The Signal Stability card looks at the variation among the latest raw readings. A tightly grouped signal is labeled Steady. Greater variation is reported as Variable or Unstable. Strength and stability are treated separately: a weak signal can still be steady, and a strong signal can fluctuate considerably.

These thresholds are sensible defaults for exploring a signal, not universal BLE rules. They are kept in a small analysis module so they can be adjusted for the advertising interval, environment, antenna, and behavior of the device being studied.

Compare nearby devices

The Discovered Now chart provides context for the focused analysis. It shows the latest RSSI from every address found during the scan, ordered from stronger to weaker signals. This is useful when choosing a target or checking how crowded the local BLE environment is.

The distribution beside it belongs only to the selected device. It counts how often recent readings occurred within each RSSI range. A narrow group of bars usually accompanies a steadier signal, while a wider spread reveals more variation. The chart can be especially useful when comparing two locations or antenna orientations that have a similar average RSSI but different consistency.

Try a simple observation

Choose a BLE advertiser that sends packets regularly and leave it in a fixed position. Let the analyzer collect readings for a short period, then change one condition at a time: rotate the device, move it farther away, place an obstacle between it and BleuIO, or walk through the signal path.

The raw samples show the immediate radio response. The smoothed line makes the larger movement easier to see, while the trend and stability cards provide a compact summary. The distribution shows whether the new condition changed only the average signal or also made it more variable.

The goal is not to turn RSSI into an exact ruler. Bluetooth radio measurements are affected by the environment, reflections, antenna orientation, and the human body. The Bluetooth SIG notes that newer Bluetooth Channel Sounding is more reliable for accurate ranging than approaches that use RSSI as a distance proxy. The Bluetooth Low Energy primer provides useful background on that distinction.

For this project, RSSI is used for what it does well: observing relative signal behavior, detecting meaningful changes, and building an experiment around real measurements.

Take the project further

The source is intentionally compact so it can be adapted. A next version could save readings to CSV, compare multiple selected devices, add experiment markers, calculate packet reception rates, or load a calibration profile for a known environment. The analysis functions can also be replaced without changing the BleuIO serial scanner or the dashboard structure.

You can find the complete application, installation instructions, and tests in the BleuIO RSSI Analyzer repository.

With a live view of both raw and processed RSSI, the project turns BleuIO into a useful signal exploration tool—and a practical foundation for more focused BLE research.

In this tutorial we will use CircuitPython to turn a Cytron MOTION 2350 Pro into a HibouAir scanner. The board’s RP2350 has no Bluetooth radio of its own. A BleuIO dongle in the board’s USB-A host port provides Bluetooth Low Energy, and a short CircuitPython program talks to it with ordinary AT commands.

The program scans for air quality monitoring device HibouAir advertisements, decodes them, and keeps the latest readings in global variables. One of them, the PM10 value from a HibouAir PM sensor, is ready to be used by the rest of your program. As an example, the program turns a hobby servo on one of the board’s servo ports into an analog PM10 gauge.

Everything runs on the board. No computer is needed once the code is in place, and the HibouAir sensors do not need to be paired.

Requirements

Hardware

• Cytron MOTION 2350 Pro
• BleuIO USB dongle. This tutorial was tested with a BleuIO Pro, firmware 1.0.7.1.
• One or more HibouAir air quality sensors. A HibouAir PM sensor is needed for the PM10 value.
• A USB-C data cable between the board and your computer
• Optional: a hobby servo for the PM10 gauge

Software

• CircuitPython 10.x for the Cytron MOTION 2350 Pro, from circuitpython.org. The tutorial uses 10.3.1.
• Two libraries from the Adafruit CircuitPython Library Bundle for version 10.x, copied into the lib folder on the CIRCUITPY drive:
  • asyncio (the whole folder)
  • adafruit_ticks.mpy, which asyncio needs

With circup installed on your computer, one command copies both:

circup install asyncio

Everything else the program uses is built into CircuitPython: usb_host, usb.core, json, binascii, microcontroller, pwmio and time. The servo is driven with pwmio directly, so it needs no extra library. No boot.py is needed.

What Does This Project Do?

1. The board becomes a USB host

The MOTION 2350 Pro’s USB-A port is driven by the RP2350’s PIO. CircuitPython starts it with usb_host.Port on GPIO24 and GPIO25. The board definition has no named pins for this port, so the program uses the raw pins.

2. CircuitPython finds BleuIO

The program waits until a device with vendor ID 0x2DCF and product ID 0x6002 appears, which is BleuIO. It selects the dongle’s configuration and sets DTR and RTS, so that BleuIO starts sending its output.

3. The dongle is brought into a known state

BleuIO remembers what it was doing, so a scan from an earlier run may still be going. The program first sends Ctrl-C three times to stop it. It then throws away everything the dongle sends until it has been quiet for 0.3 seconds. After that it sends:

• ATE0, which turns echo off
• ATV1, which turns verbose mode on, so every reply is one line of JSON

4. BleuIO scans for HibouAir only

AT+FINDSCANDATA=FF5B07

This reports only advertisements that contain FF5B07. FF is the AD type for manufacturer-specific data, and 5B 07 is HibouAir’s company ID, 0x075B, as it appears in the packet. Each result arrives as a line such as:

{"SF":127,"addr":"D9:63:8F:8E:01:0D","type":0,"data":"0201061BFF5B070504220095AE009627CF00AC014200000000000000019902"}

5. The board decodes the advertisement

The program walks the advertisement’s AD structures until it finds the HibouAir manufacturer data. This works whether or not the flags field comes first. Counting from the company ID, the sensor beacon (beacon type 0x05) holds:

Offset	Field	Format
2	Beacon type	0x05 for sensor readings
3	Board type	0x03 is the PM sensor
4–6	Sensor ID	as shown in the HibouAir app, e.g. 22026A
9	Pressure	16-bit little-endian, tenths of hPa
11	Temperature	16-bit little-endian, signed, tenths of °C
13	Humidity	16-bit little-endian, tenths of %rh
17	PM1.0	16-bit little-endian, tenths of µg/m³
19	PM2.5	16-bit little-endian, tenths of µg/m³
21	PM10	16-bit little-endian, tenths of µg/m³
23	CO2	16-bit big-endian, ppm

6. The readings are kept in global variables

• pm10: the latest PM10 value in µg/m³, or None until a PM sensor has been heard
• pm10_sensor: the ID of the sensor it came from
• pm10_time: time.monotonic() when it arrived, so that a stale value can be recognised
• sensors: a dictionary with everything the last beacon of every HibouAir sensor said, keyed by sensor ID

If you have more than one PM sensor, set PM_SENSOR_ID to the one pm10 should follow. If nothing has been heard for 15 seconds, the program starts the scan again.

Showing PM10 on a Servo Gauge

The MOTION 2350 Pro has eight servo ports, on GP0 to GP7, each with a PWM channel of its own. The program drives a servo on GP0 as a needle: 0 µg/m³ at 0 degrees, and 100 µg/m³ or more at 180 degrees.

With that full scale, the PM10 limits the HibouAir app uses fall at simple angles. That is where to draw the bands on a paper scale behind the servo arm:

PM10	Level	Needle
0–20 µg/m³	Good	0–36°
20–50 µg/m³	Fair	36–90°
50–100 µg/m³	Poor	90–180°
100 µg/m³ and above	Bad	180°

The gauge is its own asyncio task, beside the reader and the command logic:

• It sends a 50 Hz servo signal, from 500 µs at 0 degrees to 2500 µs at 180.
• It moves the needle 2 degrees every 20 ms, so the arm swings to a new reading instead of jumping.
• At start it sweeps once across the whole scale. A servo that is not connected is then noticed at once, instead of being taken for clean air.
• Once the needle has been still for half a second, the pulses stop. A servo told to hold a position holds it actively, and at 0 degrees, the commonest reading of all, it pushes against its end stop and hums. Without pulses an ordinary hobby servo goes quiet and stays where it is.
• The pulses start again when a new reading moves the needle by at least one degree, so readings of 0.0 and 0.1 µg/m³ taking turns do not wake it.

Connect the servo to the GP0 servo header, matching the servo cable to the markings next to the header. Check Cytron’s datasheet for how the servo ports are supplied before connecting a larger servo.

The settings are at the top of code.py:

• SERVO_PIN: the port, board.GP0 to board.GP7
• PM10_FULL_SCALE: the PM10 value at 180 degrees
• SERVO_MIN_US and SERVO_MAX_US: the pulse widths at the ends. Narrow them if your servo strains at its end stops.
• SERVO_STEP_DEG: how fast the needle moves
• SERVO_REST_S and SERVO_DEADBAND_DEG: how long the needle is still before it rests, and how far a reading must move it to wake it

The board’s four DC motor drivers, on GP8 to GP15 (board.M1A to board.M4B in CircuitPython), would suit a different use of the same value, such as running a fan faster as PM10 rises.

Why the Flush After Ctrl-C Matters

Ctrl-C stops the scan, but whatever BleuIO had already queued still arrives afterwards. Often the last piece is a line cut off in the middle, sometimes with a byte that is not valid UTF-8.

In early versions of this program, a reader that tried to decode that line before removing it from its buffer stuck on it. Every later piece of data was appended behind the same broken line, and the program heard nothing more, in about half of all restarts.

The program now does two things:

• It removes each line from the buffer before decoding it, so a broken line costs that line only.
• It discards everything until the dongle has been quiet before sending the next command.

With both in place, the start-up worked every time in repeated tests, whether the dongle was fresh (echo on, verbose off) or left in verbose mode by an earlier run.

How to Run the Project

Step 1: Install CircuitPython

Download the CircuitPython UF2 for the Cytron MOTION 2350 Pro and put the board into its UF2 bootloader mode. On RP2350 boards this is done by holding BOOT while pressing RESET, or while connecting the USB cable. Copy the UF2 to the RP2350 drive that appears. The board restarts as a drive named CIRCUITPY.

Step 2: Add the libraries

Run circup install asyncio, or copy the asyncio folder and adafruit_ticks.mpy from the library bundle into CIRCUITPY/lib.

Step 3: Copy the program

Save the code at the end of this post as code.py on the CIRCUITPY drive. CircuitPython starts it as soon as the file is saved.

Step 4: Connect BleuIO

Insert the BleuIO dongle into the board’s USB-A port. Do not connect BleuIO to the computer for this setup.

Step 5: Connect the servo (optional)

Plug the servo into the GP0 servo header. It sweeps once from 0 to 180 degrees and back when the program starts, then follows PM10, and goes quiet whenever the needle is still.

Step 6: Watch the serial console

Open the board’s serial console at 115200 baud. Use Mu, Thonny or the CircuitPython web workflow, or on macOS and Linux:

screen /dev/cu.usbmodem2101 115200

The device name differs from computer to computer. If the console shows raw REPL; CTRL-B to exit, an editor has left it in raw REPL mode: press Ctrl-B, then Ctrl-D to start code.py.

Expected Output

BleuIO dongle found! (0x2dcf:0x6002)
CDC Control Lines (DTR/RTS) enabled.
Starting background USB reader task...
Starting the HibouAir scan...
[Sending]: ATE0
[Sending]: ATV1
[Sending]: AT+FINDSCANDATA=FF5B07
[HibouAir 22026A] PM10 0.1 ug/m3  PM2.5 0.1  PM1 0.0  21.8 C
[HibouAir 22008C] board 0x04, 21.5 C, 39.8 %rh, CO2 459 ppm
[HibouAir 220095] board 0x04, 20.8 C, 42.9 %rh, CO2 411 ppm
[HibouAir 22005A] board 0x04, 19.6 C, 44.2 %rh, CO2 721 ppm
[HibouAir 220265] board 0x09, 19.8 C, 45.5 %rh, CO2 533 ppm

Every HibouAir sensor in range appears with its ID. Lines from the PM sensor show the particle readings; the others show temperature, humidity and CO2. Each new PM line also updates pm10.

The Code

Source code is available to download from

https://github.com/smart-sensor-devices-ab/hibouair-with-circuitpython

This project is a practical example of how BleuIO can bring Bluetooth Low Energy connectivity to development boards without built-in Bluetooth support. Using the Cytron MOTION 2350 Pro and CircuitPython, we demonstrated how to scan for HibouAir sensors, read real-time data, and use that data to control a servo motor.

The complete source code is available for developers to explore, modify, and integrate into their own projects. Whether you’re building sensor monitoring systems, automation solutions, or custom IoT applications, this example provides a starting point for using BleuIO with compatible development boards.

In this tutorial, we will build a simple BLE-to-cloud air quality gateway using HibouAir, BleuIO, Python, Cloudflare Workers, and Cloudflare D1.

A HibouAir sensor will advertise its air quality measurements over Bluetooth Low Energy. BleuIO, connected to a computer through USB, will scan for a specific HibouAir device and provide the BLE advertising data to a Python application through the serial port. The Python application will decode CO2, temperature, and humidity, display the measurements in the terminal, and upload them to a Cloudflare Worker. The Worker will then store the measurements in a Cloudflare D1 database.

This project is intentionally kept simple. It demonstrates how BleuIO can act as the Bluetooth interface for a desktop or gateway application without requiring the application itself to manage a Bluetooth stack.

Why Cloudflare D1?

Cloudflare D1 is a serverless SQL database built on SQLite. It works particularly well with Cloudflare Workers, allowing us to create a small HTTP API without running our own server.

For a project like this, there are several advantages:

• No database server to install or maintain
• No local web server required
• HTTPS is handled automatically
• Cloudflare Workers can communicate directly with D1
• D1 supports regular SQL
• A useful free tier is available
• The database remains accessible even when the Computer running the BLE gateway is offline

This makes it convenient for prototypes, BLE gateways, environmental monitoring projects, demonstrations, and small IoT applications.

For this example, the Computer only needs to run the Python gateway application. Everything after the HTTP request is handled in the cloud.

Requirements

For this project, you will need:

Hardware

• BleuIO USB Bluetooth Low Energy dongle
• HibouAir CO2 air quality sensor

Software and services

• Python 3
• A free Cloudflare account
• pyserial
• requests

For this example, the HibouAir sensor has the board ID:

220069

and BleuIO appears on the Mac at:

/dev/cu.usbmodem4048FDEBA6D01

Your serial port depends on operating system and HibouAir board ID may be different.

Step 1: Create a Cloudflare D1 Database

First, log in to your Cloudflare account.

From the Cloudflare dashboard, go to the D1 database section and create a new database.

For this tutorial, we will call it:

hibouair-db

Once the database has been created, open its SQL Console.

Run the following SQL:

CREATE TABLE IF NOT EXISTS readings (
    id INTEGER PRIMARY KEY AUTOINCREMENT,
    board_id TEXT NOT NULL,
    measured_at TEXT NOT NULL DEFAULT CURRENT_TIMESTAMP,
    co2 INTEGER NOT NULL,
    temperature REAL NOT NULL,
    humidity REAL NOT NULL
);

CREATE INDEX IF NOT EXISTS idx_readings_board_time
ON readings(board_id, measured_at);

This creates a simple table containing:

• Database ID
• HibouAir board ID
• Timestamp
• CO₂
• Temperature
• Humidity

The measured_at field is generated automatically by D1 when the reading is inserted.

A stored record will look conceptually like this:

id          1
board_id    220069
measured_at 2026-10-05 14:42:30
co2         623
temperature 24.1
humidity    43.7

Step 2: Create the Cloudflare Worker

Next, create a Cloudflare Worker.

Now go to:

Workers & Pages → Create application

Create a basic Worker. ( you can choose “Start with Hello world”)

The Worker will sit between our Python application and the D1 database.

For this project, we can name it:

hibouair-api

and then press deploy.

After creating the Worker, open the code editor and replace the default code with the following :

export default {
  async fetch(request, env) {
    const url = new URL(request.url);

    // API status
    if (url.pathname === "/" && request.method === "GET") {
      return Response.json({
        service: "HibouAir Cloud API",
        status: "online"
      });
    }

    // Store a new sensor reading
    if (url.pathname === "/api/readings" && request.method === "POST") {
      const suppliedKey = request.headers.get("X-API-Key");

      if (!suppliedKey || suppliedKey !== env.API_KEY) {
        return Response.json(
          {
            success: false,
            error: "Unauthorized"
          },
          {
            status: 401
          }
        );
      }

      let data;

      try {
        data = await request.json();
      } catch {
        return Response.json(
          {
            success: false,
            error: "Invalid JSON"
          },
          {
            status: 400
          }
        );
      }

      const boardId = String(data.board_id || "").trim();
      const co2 = Number(data.co2);
      const temperature = Number(data.temperature);
      const humidity = Number(data.humidity);

      if (!boardId) {
        return Response.json(
          {
            success: false,
            error: "board_id is required"
          },
          {
            status: 400
          }
        );
      }

      if (
        !Number.isFinite(co2) ||
        !Number.isFinite(temperature) ||
        !Number.isFinite(humidity)
      ) {
        return Response.json(
          {
            success: false,
            error: "Invalid sensor values"
          },
          {
            status: 400
          }
        );
      }

      const result = await env.DB
        .prepare(`
          INSERT INTO readings (
            board_id,
            co2,
            temperature,
            humidity
          )
          VALUES (?, ?, ?, ?)
        `)
        .bind(
          boardId,
          co2,
          temperature,
          humidity
        )
        .run();

      return Response.json({
        success: true,
        message: "Reading stored",
        board_id: boardId,
        co2: co2,
        temperature: temperature,
        humidity: humidity,
        meta: result.meta
      });
    }

    // Return the latest reading
    if (
      url.pathname === "/api/readings/latest" &&
      request.method === "GET"
    ) {
      const boardId =
        url.searchParams.get("board_id") || "220069";

      const reading = await env.DB
        .prepare(`
          SELECT
            id,
            board_id,
            measured_at,
            co2,
            temperature,
            humidity
          FROM readings
          WHERE board_id = ?
          ORDER BY id DESC
          LIMIT 1
        `)
        .bind(boardId)
        .first();

      if (!reading) {
        return Response.json(
          {
            success: false,
            error: "No readings found"
          },
          {
            status: 404
          }
        );
      }

      return Response.json({
        success: true,
        reading: reading
      });
    }

    return Response.json(
      {
        success: false,
        error: "Not found"
      },
      {
        status: 404
      }
    );
  }
};

Deploy the Worker.

At this stage, the Worker exists, but it is not yet connected to the D1 database.

Step 3: Bind the D1 Database to the Worker

Open the settings for the hibouair-api Worker.

Add a D1 database binding.

Use:

Variable name: DB
Database: hibouair-db

The variable name must be:

DB

because the Worker accesses the database through:

env.DB

For example:

await env.DB
    .prepare("SELECT * FROM readings")
    .all();

Once the binding has been added, deploy the Worker again if necessary.

Step 4: Add an API Key

Our Python application will be publicly connected to the Cloudflare Worker over HTTPS.

We therefore do not want anybody who discovers the Worker URL to be able to insert arbitrary sensor measurements.

We can protect the write endpoint using a simple API key.

On the Computer, generate a random key:

python3 -c "import secrets; print(secrets.token_hex(32))"

This will generate a long random value.

Copy it.

Now create a Worker secret environment variable named:

API_KEY

and paste the generated value as its value.

The Python application will include this key in every request using:

X-API-Key

The Worker checks:

const suppliedKey =
    request.headers.get("X-API-Key");

and compares it against:

env.API_KEY

Step 5: Test the Worker

Cloudflare will provide a Worker URL similar to:

https://hibouair-api.your-account.workers.dev

Open the base Worker URL in a browser.

You should receive something similar to:

{
  "service": "HibouAir Cloud API",
  "status": "online"
}

If you see this response, the Worker is running.

Our Python application will send measurements to:

https://hibouair-api.your-account.workers.dev/api/readings

The latest stored reading can later be retrieved from:

https://hibouair-api.your-account.workers.dev/api/readings/latest

Step 6: Download the Python Project

The source code for the BleuIO Python gateway is available on GitHub:

GitHub: https://github.com/smart-sensor-devices-ab/bleuio-cloudflare-d1-database

Clone the repository:

git clone https://github.com/smart-sensor-devices-ab/bleuio-cloudflare-d1-database

Then enter the project directory:

cd bleuio-cloudflare-d1-database

The project structure is intentionally small:

bleuio-cloudflare-d1/
│
├── main.py
├── info.example.txt
├── requirements.txt
└── .gitignore

The Python application handles:

1. Connecting to BleuIO
2. Sending BleuIO AT commands
3. Searching for the HibouAir board ID
4. Reading BLE advertising data
5. Decoding CO2, temperature, and humidity
6. Displaying the measurement in the terminal
7. Sending the measurement to Cloudflare
8. Repeating the process at a configurable interval

Step 7: Install the Python Dependencies

It is recommended to create a Python virtual environment.

Run:

python3 -m venv .venv

Activate it:

source .venv/bin/activate

Then install the required libraries:

pip install -r requirements.txt

The application only requires:

pyserial
requests

pyserial is used to communicate with BleuIO through the USB serial port.

requests is used to send the decoded measurements to the Cloudflare Worker over HTTPS.

Step 8: Configure the Project

The repository includes:

info.example.txt

Copy it:

cp info.example.txt info.txt

Then open:

info.txt

The configuration looks like this:

BLEUIO_PORT=/dev/cu.usbmodem4048FDEBA6D01
HIBOUAIR_SENSOR_ID=220069

SCAN_INTERVAL_SECONDS=30

CLOUDFLARE_API_URL=https://hibouair-api.YOUR-SUBDOMAIN.workers.dev/api/readings
CLOUDFLARE_API_KEY=YOUR_REAL_API_KEY

You need to update the values for your own environment.

BLEUIO_PORT

On our Mac, BleuIO is available at:

/dev/cu.usbmodem4048FDEBA6D01

Your port may be different.

You can normally find USB serial devices with:

ls /dev/cu.*

Look for the device corresponding to BleuIO.

On windows , look for COM port on device manager.

HIBOUAIR_SENSOR_ID

For this project, our HibouAir board ID is:

220069

Replace this with the board ID of the HibouAir device you want to monitor.

SCAN_INTERVAL_SECONDS

This determines how often the application starts a new HibouAir scan.

For this tutorial:

SCAN_INTERVAL_SECONDS=30

means approximately one scan every 30 seconds.

You can later change this without modifying the Python source code.

For example:

SCAN_INTERVAL_SECONDS=60

for approximately one reading per minute.

Or:

SCAN_INTERVAL_SECONDS=300

for approximately one reading every five minutes.

CLOUDFLARE_API_URL

Replace this with the URL of the Worker created earlier:

CLOUDFLARE_API_URL=https://hibouair-api.YOUR-SUBDOMAIN.workers.dev/api/readings

CLOUDFLARE_API_KEY

Enter the same secret that was configured in the Cloudflare Worker:

CLOUDFLARE_API_KEY=YOUR_REAL_API_KEY

The info.txt file should not be committed to GitHub because it contains the API key.

Step 9: How the HibouAir Data Is Read

BleuIO communicates with our Python application using simple AT commands over the serial port.

The application first connects to BleuIO and places it in central mode.

It then searches for our HibouAir board ID using:

AT+FINDSCANDATA=220069=5

Here:

220069

is the HibouAir board ID, and:

5

defines the scan duration.

BleuIO handles the Bluetooth Low Energy scanning and returns the matching BLE advertising information over serial.

This means the Python application does not need to directly communicate with the operating system’s native Bluetooth API.

BleuIO then returns the advertising data to Python.

Step 10: Decode the HibouAir Advertisement

The Python application searches the advertising payload for the HibouAir data section:

5B070

For the HibouAir advertisement used in this example, the application extracts the three measurements needed for this project. Temperature, Humidity and CO2. The result becomes a normal Python structure similar to:

{
    "co2": 623,
    "temperature": 24.1,
    "humidity": 43.7
}

The application also performs basic validation before uploading the measurements.

For example, obviously invalid temperature, humidity, or CO2 values are rejected instead of being stored in the database.

Step 11: Sending the Measurement to Cloudflare

Once a valid advertisement has been decoded, Python prepares a JSON request.

For example:

{
  "board_id": "220069",
  "co2": 623,
  "temperature": 24.1,
  "humidity": 43.7
}

This is sent using an HTTP POST request to:

/api/readings

The API key is included in the request header:

X-API-Key

The Cloudflare Worker validates the key and inserts the measurement into D1.

The Python application therefore never connects directly to the database.

Step 12: Run the Application

Before running the project, make sure no other program is currently using the BleuIO serial port.

For example, close any active BleuIO connection in:

• BleuIO application
• screen
• serial monitor
• terminal program
• other Python application

Then run:

python3 main.py

The application should connect to BleuIO.

You should see output similar to:

BleuIO + HibouAir + Cloudflare D1
---------------------------------

BleuIO port : /dev/cu.usbmodem4048FDEBA6D01
HibouAir ID : 220069
Scan interval: 30 seconds

Trying BleuIO on /dev/cu.usbmodem4048FDEBA6D01 at 115200 baud...

BleuIO connected successfully.

Setting BleuIO to central mode...
Ready.

The application will then start scanning:

Scanning for HibouAir 220069...

Command: AT+FINDSCANDATA=220069=5

When a valid HibouAir advertisement is received and decoded, the terminal will display something similar to:

============================================
          HIBOUAIR AIR QUALITY
============================================

  CO2                623 ppm
  Temperature       24.1 °C
  Humidity          43.7 %RH

============================================

Uploading to Cloudflare D1...
✓ Reading stored successfully.

Next scan in 23 seconds...

The application continues running automatically.

There is no need to restart it for each measurement.

To stop the application, press:

Ctrl + C

Step 13: Check the Data in Cloudflare D1

Now return to the Cloudflare D1 database console.

Run:

SELECT *
FROM readings
ORDER BY id DESC
LIMIT 10;

You should see the measurements coming from HibouAir.

For example:

id  board_id  measured_at          co2  temperature  humidity

12  220069    2026-10-05 14:58:20  618  24.1         43.8
11  220069    2026-10-05 14:57:50  621  24.1         43.8
10  220069    2026-10-05 14:57:20  623  24.1         43.7

You can also explore the data from your database.

Step 14: Check the Latest Reading Through the API

We also created a simple read endpoint.

Open:

https://YOUR-WORKER.workers.dev/api/readings/latest

The Worker will query D1 and return the latest measurement.

For example:

{
  "success": true,
  "reading": {
    "id": 12,
    "board_id": "220069",
    "measured_at": "2026-10-05 14:58:20",
    "co2": 618,
    "temperature": 24.1,
    "humidity": 43.8
  }
}

Building a Dashboard Later

This tutorial intentionally stops at the database and API level.

The objective is to demonstrate the complete BLE-to-cloud data path while keeping the example easy to understand.

At this point, the data is already available in the cloud.

A developer could later build a dashboard showing:

Current CO₂
Current Temperature
Current Humidity

CO₂ history
Temperature history
Humidity history

A dashboard could request historical readings through additional Worker API endpoints.

It could also display thresholds, warnings, averages, minimum/maximum measurements, or other analytics.

Those features are deliberately outside the scope of this example because the main goal is to demonstrate how easily BLE data can be brought into a serverless cloud architecture using BleuIO.

We kept the project intentionally simple so that the individual parts are easy to understand and modify.

From here, the project can be expanded in many directions. Multiple HibouAir sensors could be monitored, additional air quality parameters could be stored, historical API endpoints could be created, and a complete cloud dashboard could be built on top of the existing data.

In this project, we will look at how the BleuIO SSD025 Bluetooth Low Energy USB dongle can add BLE communication to an Adafruit Fruit Jam powered by the RP2350.

The project takes an unusual software approach. Instead of running the HibouAir scanner as part of the native firmware, the Fruit Jam runs a custom real-time operating system called myRTOS .

A myRTOS application module, hibouair.c, written in C, communicates with the BleuIO dongle over USB, scans for nearby HibouAir air-quality sensors, decodes their Bluetooth Low Energy advertisements and displays the latest measurements in real time in a terminal window.

The result is a compact embedded BLE air-quality gateway running on the RP2350.

Requirements

For this project, we use:

• Adafruit Fruit Jam with RP2350B
• BleuIO SSD025 Bluetooth Low Energy USB dongle
• One or more HibouAir SSD002 air-quality sensors
• myRTOS
• USB data cable
• Computer with a serial terminal such as PuTTY

The Fruit Jam is particularly suitable for this project because it has a built-in USB hub with two exposed USB host ports.

What does this project do?

1. HibouAir broadcasts sensor data

2. BleuIO receives the BLE advertisements

3. Fruit Jam receives the data over USB

4. myRTOS decodes and displays the measurements

The HibouAir sensor periodically broadcasts its measurements using BLE advertising packets. The SSD025 receives these packets and makes the information available to the RP2350 over USB.

The myRTOS application then scans for HibouAir devices, interprets the received information and maintains a live list of detected sensors.

The terminal provides an easy way to observe the air-quality information as it arrives.

Hardware

The project is built around three main pieces of hardware.

Adafruit Fruit Jam with the BleuIO SSD025 connected directly to the USB Type-A host port.

Adafruit Fruit Jam

The Fruit Jam is a compact computer based on the RP2350B microcontroller. Adafruit provides two USB Type-A host ports through an onboard USB hub, making it possible to connect USB peripherals directly to the board.

The board provides considerably more functionality than is required for this simple gateway. In addition to the RP2350B, it includes flash storage, PSRAM, USB host capability, microSD, DVI output, audio hardware and an ESP32-C6 for wireless connectivity.

For this project, however, the important feature is the USB host interface .

BleuIO SSD025

The BleuIO SSD025 is used as the Bluetooth Low Energy interface.

This means the RP2350 application does not need to implement the Bluetooth Low Energy stack itself.

The dongle supports Bluetooth 5.2 and USB Full Speed, can operate in Bluetooth central or peripheral roles, and is controlled through its USB interface.

The application can therefore access BLE functionality through BleuIO’s USB interface while leaving the Bluetooth communication to the dongle.

HibouAir SSD002

The HibouAir SSD002 is the wireless air-quality sensor.

HibouAir’s documentation describes the SSD002/2B as a CO2 air-quality monitor using an NDIR CO2 sensor, with wireless Bluetooth connectivity. The sensor family can provide environmental parameters including CO2, temperature, humidity, particulate matter and VOC-related measurements depending on the model.

www.hibouair.com

Why use BleuIO?

The BleuIO acts as the bridge between the USB host implemented by the Fruit Jam and the Bluetooth Low Energy devices in the surrounding environment.

The application processor can concentrate on:

• USB communication
• RTOS scheduling
• data parsing
• terminal output

while the BleuIO handles the Bluetooth side.

BleuIO’s own HibouAir gateway example similarly uses BleuIO to provide BLE communication to RP2040/RP2350 development boards through USB.

The Software Architecture

The software in this project is based on myRTOS , a small real-time operating system environment running on the Fruit Jam.

The HibouAir application is started from the RTOS command interface:

myrtos:/> hibouair

Once started, the application enters scanning mode:

scanning; ctrl-C to stop

The application then continuously processes incoming BLE data.

Conceptually, the software pipeline looks like this:

HibouAir → BLE advertisements → BleuIO SSD025 → USB → Fruit Jam / myRTOS → HibouAir packet decoding → Terminal display

The important point is that this is not simply a raw BLE packet monitor.

The application turns the incoming wireless data into a human-readable sensor table .

How to Run the Project

The complete project is available on GitHub:

https://github.com/smart-sensor-devices-ab/Adafruit-Fruit-Jam-with-BleuIO

1. Connect the board: Connect the Adafruit Fruit Jam to your computer using a USB-C cable and turn the power switch ON.
2. Hold down Button #1 (the UF2 BOOT button located on GPIO0), press and release the reset button while continuing to hold Button #1, and release Button #1 only after the bootloader drive appears.
3. Drag the project’s .uf2 file onto the board’s bootloader drive. The image includes myRTOS and the hibouair.c application module.
4. Press the reset button to reboot the board.
5. Connect the BleuIO SSD025: Plug the BleuIO SSD025 into one of the Fruit Jam’s USB Type-A host ports.
6. Power the HibouAir sensor: Make sure one or more HibouAir sensors are powered on and within Bluetooth range of the BleuIO dongle.

Button Locations on the Adafruit Fruit Jam

To enter UF2 bootloader mode, this project uses two buttons on the Fruit Jam:

• Button #1 (UF2 BOOT) — located on GPIO0 towards the bottom-right edge of the board.
• Reset button — located on the left edge of the board.

The image below shows the location of both buttons.

After rebooting, open a terminal window and connect to the board.

Windows

After rebooting, open Device Manager and identify the COM port assigned to the Fruit Jam. Connect to this port using a serial terminal such as PuTTY.

macOS

To find the Fruit Jam’s serial port, open a terminal and run:

ls /dev/cu.usbmodem*

The command should return a device similar to:

/dev/cu.usbmodem2351xxxx

Connect to it using:

screen /dev/cu.usbmodem2351xxxx

Real-Time HibouAir Scanning

After connecting to the Fruit Jam, start the HibouAir application from the myRTOS command interface:

myrtos:/> hibouair

scanning; ctrl-C to stop

The program then prints a table containing the detected HibouAir devices.

This gives the user an immediate overview of all the HibouAir sensors currently being received.

Expected Output

For example, the output below shows several HibouAir devices detected during a scan. The table shows each detected device’s board identifier, Bluetooth address, sensor type and latest environmental measurements.

Where Could This Go Next?

The current application concentrates on the essential task: receiving HibouAir advertisements and presenting the decoded measurements in real time.

Logging the data to the Fruit Jam’s microSD card would also make it possible to create long-term air-quality datasets without requiring a permanently connected computer.

The Fruit Jam’s USB host capability, microSD storage and RP2350B processor make this type of expansion practical.

Conclusion

This project demonstrates how the Adafruit Fruit Jam, BleuIO SSD025 and HibouAir SSD002 can be combined to create a compact RP2350-based Bluetooth Low Energy air-quality gateway.

HibouAir sensors broadcast their environmental measurements over BLE. BleuIO receives these advertisements and transfers the data to the Fruit Jam over USB, where the myRTOS hibouair application decodes the sensor data and presents the latest measurements in real time.

The project shows how BleuIO can add BLE communication to an RP2350-based embedded system while keeping the Bluetooth interface separate from the main application.
